Conical jet nozzle model “S” CMW CO2 Technologies

Conical jet nozzle model “S”

  • Material:  Delrin®
  • Pressure: 0 – 12 bar
  • Dimensions: 60 mm x 20 mm | Ø Out: 8.0 mm | 1/2″ BSP
  • Dimensions: 80 mm x 22 mm | Ø Out: 7.3 mm | 3/4″ BSP
  • Weight: 24 gm | 31 gm

Specially designed for cleaning delicate surfaces (e.g. plastics molds), under-voltage cryogenic cleaning and the restoration of surfaces with complex geometry with restricted access.

Conical jet nozzle - M CMW CO2 Technologies

Cone jet nozzle model “M”

  • Material:  Delrin®
  • Pressure: 0 – 12 bar
  • Dimensions: 100 mm x 20 mm | Ø Out: 8.5 mm | 1/2″ BSP
  • Dimensions: 100 mm x 22 mm | Ø Out: 8.0 mm | 3/4″ BSP
  • Weight: 40 gm | 47 gm

Specially designed for cleaning delicate surfaces (e.g. plastics molds), under-voltage cryogenic cleaning and the restoration of surfaces with complex geometry with restricted access. High cleaning power.

Low_Consumption_Delrin CMW CO2 Dry Ice

Low consumption compressed air nozzle “S”

  • Material:  Delrin®
  • Pressure: 0 – 12 bar
  • Dimensions: 155mm x 16mm | Ø Out: 5.8 mm | 1/2″ BSP
  • Weight: 50g

Specially designed for cleaning delicate surfaces (e.g. plastics molds), under-voltage cryogenic cleaning.

Medium_Concumption_Delrin CMW CO2 Dry Ice

Average compressed air consumption nozzle “M”

  • Material:  Delrin®
  • Pressure: 0 – 12 bar
  • Dimensions BSM/D: 160mm x 16mm | Ø Out: 7.2 mm | 1/2″ BSP
  • Dimensions BSM/D/A: 160 mm x 16 mm | Ø Out: 7.2 mm | 3/4″ BSP
  • Weight BSM/D: 50 gr | Weight BSM/D/A  : 57 gr

Specially designed for cleaning delicate surfaces (e.g. plastics molds), under-voltage cryogenic cleaning. High cleaning power.

High_Consumption_Delrin CMW CO2 Technologies

Average compressed air consumption nozzle “L”

  • Material:  Delrin®
  • Pressure: 0 – 12 bar
  • Dimensions BSL/D: 165mm x 16mm | Ø Out: 8.0 mm | 1/2″ BSP
  • Dimensions BSL/D/A: 165mm x 16mm | Ø Out: 8.0 mm | 3/4″ BSP
  • BSL/D weight: 48 gr | Weight BSL/D/A: 55 gr

Specially designed for cleaning delicate surfaces (e.g. plastics molds), under-voltage cryogenic cleaning.
